Ultrapen PT6 Nitrat ve Sıcaklık Kalemi
Ultrapen PT6 Nitrat ve Sıcaklık Kalemi
ULTRAPEN™ PT6 Benefits:
- Reliable Repeatable Results
- Accurate
- Affordable
- Easy to Use
- Rugged Design
- Ensure Product Quality
- Reduce Waste
- Protect the Environment
ULTRAPEN™ PT6 High Performance Features:
- Nitrate Concentration (ppm N or ppm NO3—) or mV
- 1 and 2 Point Calibration Options
- Proprietary ISE Sensor Design
- Built-in Double Junction Reference Electrode
- Compatible with EPA Approved Standard Method 4500-NO3— D
- Live or Hold Mode – User Selectable
- Auto-Off Feature – User Adjustable
- Easy to Use – One Button Control
- Rugged Design with Aircraft Aluminum Body
- Durable, Epoxy Encapsulated Electronics
- Waterproof
- Powered by One N Type Battery (Included)
ULTRAPEN™ PT6 COMES WITH:
- PT6 Pocket Tester Pen – Battery Installed
- User Replaceable Nitrate Sensor – Installed
- 100 ppm NO3— -N Standard Solution – 2 oz.
- Ionic Strength Adjuster (ISA) – 2 oz.
- Graduated Cylinder with Cap – 2 ea.
- 100 μL Pipette – with Tip
- Protective Cap
- Pocket Clip
- PT6 Operation Manual
ULTRAPEN™ PT6 Measurement Modes:
| MODE | METHOD OF MEASUREMENT |
| Hold | Displays real-time readings until the LED turns solid ON, then displays final readings. |
| LIVE | Displays real-time readings continuously for up to 5 minutes. |
ULTRAPEN™ PT6 Parameter Modes:
| MODE | PARAMETER MEASURED |
| N | Display alternates between Nitrate as Nitrogen (NO3—N), and Temperature |
| NO3 | Display alternates between Nitrate (NO3—), and Temperature |
| mV | Display alternates between millivolt (mV), and Temperature |
ULTRAPEN™ PT6 Specifications:
| Specifications | Nitrate as Nitrogen NO3—N | Nitrate NO3— | Temperature |
| Ranges | 1-1400 ppm | 4.4-6200 ppm | 0 – 71°C / 32 – 160°F |
| Accuracy1 | ± 10% of the reading | ± 10% of the reading | ± 0.1°C |
| Resolution | 0.1 ppm | 0.1 ppm | 0.1°C/F |
| pH Range: | 3-11 pH |
| Time to Reading Stabilization: | 10 – 180 seconds |
| Power Consumption: Active Mode: | 30 – 140 mA, Sleep Mode: 2 μA |
| Physical Dimensions: | 17.15 cm L x 1.59 cm D or 6.75 in. L x .625 in. D |
| Weight: | 54 g or 1.94 oz. |
| Case Material: | Anodized Aircraft Aluminum with Protective Coating |
| Battery Type: | N type, Alkaline 1.5 V |
| Calibration Standard Solutions: | 1, 10, 100, or 1000 ppm NO3—N |
| Operating/Storage Temperature: | 0-40°C / 32-104°F 2 |
| Enclosure Ratings: | IP67 and NEMA 6 |
| EN61236-1: 2006 – Annex A: 2008; Electrostatic discharge to case of instrument may cause PT6 to spontaneously power ON. In this case, the PT6 will power OFF after several seconds. | |
1 Accuracy of measuring standard solutions after Temperature Controlled, 2-Point Calibration with one order of concentration difference.
2 For extended life of the sensor, store the pen in a cool location (5-25 ̊C)
ULTRAPEN™ PT6 Applications:
- Animal Drinking Water
- Animal Manure
- Aquariums, Fresh Water
- Aquariums, Salt Water
- Effluent from Waste Water Treatment Plants
- Fruit and Vegetables plant tissue (petiole) sap
- Industrial Discharge
- Rivers, Streams, Lakes
- Septic Systems
- Soil test for Agriculture
- Storm Water Runoff
- Waste Water Treatment
- Well Water
- Landfills
ULTRAPEN™ PT6 Accessories:
The ULTRAPENTM PT6 can be calibrated with 1, 10, 100, or 1000 ppm NO3—N Calibration Solution
Order Models:
- N1SOL – 1 ppm NO3—N (Nitrate as Nitrogen) Standard Solution
- N10SOL – 10 ppm NO3—N (Nitrate as Nitrogen) Standard Solution
- N100SOL – 100 ppm NO3—N (Nitrate as Nitrogen) Standard Solution
- N1000SOL – 1000 ppm NO3—N (Nitrate as Nitrogen) Standard Solution
- Ionic Strength Adjuster
Order Model: NISASOL
- Nitrate Interference Suppression Buffer:
Order Model: NISBSOL
- Replacement Nitrate Sensor:
Order Model: RPT6
